Midea 1.5HP Split Wall Mounted Type Air-Cond Xtreme MSXD-12CRN8

• Golden fin

• Air magic

• Cold Catalyst Filter

• Low Noise

• Smart Diagnosis

• Follow Me

• WIFI Control (optional)



• 1.5HP

• Application Area : 130-190sq.ft

• Indoor air flow (H) : 600 (353) m3/h(cfm)

• Indoor Sound level (H/L) : 41/30 dB(A)

• Dimension(W*D*H) : 835x208x295 mm

• Packing (W*D*H) : 905x355x290 mm

• Net/Gross weight : 9.3/11.9 Kg



• Outdoor Sound level : 52 dB(A)

• Dimension(W*D*H) : 765x303x555 mm

• Packing (W*D*H) : 887x337x610 mm

• Net/Gross weight : 27.3/29.7 Kg

• Refrigerant Charge : R32/430g

• Design pressure : 4.3/1.7 MPa



Refrigerant piping

• Liquid side/ Gas side : Φ6.35/Φ9.52(1/4/3/8) mm(inch)

• Max. refrigerant pipe length : 20 m

• Max. difference in level : 8 m



• Cooling Capacity : 12,000 Btu/h

• Power consumption : 1053 W

• Running current : 4.58 A

• CSPF(Cooling seasonal performance factor) : 3.62 Wh/Wh

• Power supply : 220-240V~,50Hz,1Ph (power supply to indoor) V,Hz,Ph

• Indoor-Outdoor connection wiring (Not included) : 3x1.5 mm2

• Power supply wiring(Not included wire) : 3x1.5 mm2

• Thermostat type : Wireless Remote Control (Wifi control, Wire control optional)





2 Years Full Warranty by Midea Malaysia

5 Years Compressor Warranty by Midea Malaysia
